4 basic requirements of machine tool clamping device
The purpose of the design of the clamping device is to facilitate the clamping of the workpiece. The composition and basic requirements of a complete clamping device are as follows: (1) force source device; (2) intermediate force transmission mechanism; (3) clamping elements.
The 4 basic requirements of the clamping device are.
(1) in the clamping process should be able to maintain the accurate positioning obtained when positioning the workpiece.
(2) the size of the clamping force should be appropriate to ensure the stability of the workpiece positioning during processing, but also to prevent damage to the surface of the workpiece due to excessive clamping force or excessive clamping deformation of the workpiece.
(3) clamping device should be easy to operate, labor-saving, safe.
(4) the complexity of the clamping device and the degree of automation should be adapted to the workpiece production batch and production methods.
Clamping mechanism
There are six common clamping mechanisms, namely: inclined wedge clamping mechanism, spiral clamping mechanism, eccentric clamping mechanism, centering clamping mechanism, linkage clamping mechanism and clamping power unit.
