Basic Principles Of Fixture Design

Basic principles of fixture design

1. Meet the stability and reliability of workpiece positioning during use;

2. There is sufficient bearing or clamping force to ensure the processing process of workpiece on the tooling;

3. Meet the requirements of simple and fast operation in the clamping process;

4. The vulnerable parts must be of a structure that can be quickly replaced, and it is better not to use other tools when conditions are sufficient;

5. Meet the reliability of repeated positioning of fixture during adjustment or replacement;

6. Avoid complex structure and high cost as much as possible;

7. Standard parts shall be selected as components as far as possible;

8. To form the systematization and standardization of the company’s internal products.
