Common fixtures are classified according to their functions
Fixture design is generally carried out according to the specific requirements of a process after the mechanical processing process of parts is formulated. The possibility of fixture realization shall be fully considered when formulating the technological process. When designing the fixture, if necessary, the technological process can also be modified. The design quality of the fixture shall be measured by whether it can stably guarantee the processing quality of the workpiece, high production efficiency, low cost, convenient chip removal, safe operation, labor saving and easy manufacturing and maintenance.
Commonly used jigs and fixtures are mainly divided into the following categories according to their functions:
01 Clamp mold
02 Drilling and milling tooling
03 NC and instrument collet
04 Gas test and water test tooling
05 Trimming and punching tooling
06 Welding tooling
07 Polishing fixture
08 Assembly tooling
09 Printing and laser engraving tooling
